MAX98357 I2S Amp

A digital-to-analog converter (DAC) and class D amplifier combined into one module, using the I2S digital audio standard.

Component Preview

MAX98357A

Unlike simple buzzers or analog amplifiers, the MAX98357A accepts a pure digital I2S audio stream. It converts this digital stream internally to analog and amplifies it to drive a 4Ω to 8Ω speaker directly, providing much cleaner audio than PWM-based approaches.

ActuatorsAudioI2S

Overview

I2S (Inter-IC Sound) is a standardized serial bus used for connecting digital audio devices. It is completely different from I2C. The ESP32 and other advanced microcontrollers have dedicated I2S hardware peripherals that can stream high-quality audio files directly to this module.

Pin Reference

Pin	Type	Description
LRC	input	Left/Right Clock (Word Select). Tells the DAC whether the current data is for the left or right channel.
BCLK	input	Bit Clock. The clock signal that synchronizes the data bits.
DIN	input	Data In. The actual digital audio data stream.
GAIN	analog	Gain Select. Leaves floating for 9dB gain. Connect to GND for 12dB.
SD	input	Shutdown / Channel Select. Used to configure mono mixing or shut down the amp.
GND	power	Ground.
VIN	power	Power Supply (2.5V - 5.5V). Connect to 3.3V or 5V.
OUT+	output	Positive terminal for speaker connection.
OUT-	output	Negative terminal for speaker connection.

Configurable Attributes

This component has no standard configurable attributes.

Wiring Diagram (ESP32 Example)

1. Connect VIN to ESP32 5V (or 3.3V).
2. Connect GND to ESP32 GND.
3. Connect LRC to ESP32 GPIO 25.
4. Connect BCLK to ESP32 GPIO 26.
5. Connect DIN to ESP32 GPIO 22.
6. Connect OUT+ and OUT- to a speaker.

Example Arduino Code (ESP32)

This example uses the ESP32's built-in I2S driver to stream a basic sine wave or read from an SD card.

#include <driver/i2s.h>

// I2S Pins
#define I2S_BCLK 26
#define I2S_LRC  25
#define I2S_DOUT 22

void setup() {
  Serial.begin(115200);

  // Configure I2S peripheral
  i2s_config_t i2s_config = {
    .mode = (i2s_mode_t)(I2S_MODE_MASTER | I2S_MODE_TX),
    .sample_rate = 44100,
    .bits_per_sample = I2S_BITS_PER_SAMPLE_16BIT,
    .channel_format = I2S_CHANNEL_FMT_ONLY_LEFT,
    .communication_format = I2S_COMM_FORMAT_STAND_I2S,
    .intr_alloc_flags = ESP_INTR_FLAG_LEVEL1,
    .dma_buf_count = 8,
    .dma_buf_len = 64,
    .use_apll = false
  };

  i2s_pin_config_t pin_config = {
    .bck_io_num = I2S_BCLK,
    .ws_io_num = I2S_LRC,
    .data_out_num = I2S_DOUT,
    .data_in_num = I2S_PIN_NO_CHANGE
  };

  i2s_driver_install(I2S_NUM_0, &i2s_config, 0, NULL);
  i2s_set_pin(I2S_NUM_0, &pin_config);
  i2s_set_clk(I2S_NUM_0, 44100, I2S_BITS_PER_SAMPLE_16BIT, I2S_CHANNEL_MONO);
}

void loop() {
  // Generate a simple square wave tone manually for demonstration
  int16_t sample = 10000;
  size_t bytes_written;

  for (int i = 0; i < 50; i++) {
    i2s_write(I2S_NUM_0, &sample, sizeof(sample), &bytes_written, portMAX_DELAY);
  }

  sample = -10000;
  for (int i = 0; i < 50; i++) {
    i2s_write(I2S_NUM_0, &sample, sizeof(sample), &bytes_written, portMAX_DELAY);
  }
}

Simulation Notes

• Audio playback inside the simulator depends on your browser's audio policies. You may need to interact with the canvas (click a button) before sound is allowed to play.
• Performance varies based on how demanding the I2S decoding is; ESP32 is generally required for smooth audio emulation.

---
